WiFi router TP-Link EAP610-Outdoor venkovní AP, 1x GLAN, 2,4 a 5 GHz, AX1800, Omáda SDN -

HARDWARE FEATURES Interface 1× Gigabit Ethernet (RJ-45) Port (Support 802.3at PoE and Passive PoE) Button Reset Power Supply • 802.3at PoE • 48V/0.5A Passive PoE (PoE Adapter Included) Power Consumption • EU: 12.5W (802.3at PoE or Passive PoE) • US: 14.7W (802.3at PoE or Passive PoE) Dimensions... číst celé

HARDWARE FEATURES Interface 1× Gigabit Ethernet (RJ-45) Port (Support 802.3at PoE and Passive PoE) Button Reset Power Supply • 802.3at PoE

• 48V/0.5A Passive PoE (PoE Adapter Included)

Power Consumption • EU: 12.5W (802.3at PoE or Passive PoE)

• US: 14.7W (802.3at PoE or Passive PoE)

Dimensions ( W x D x H ) • 280.4×106.5×56.8 mm (without antenna & mounting kit) Antenna • 2.4 GHz: 2× 4 dBi

• 5 GHz: 2× 5 dBi

Weatherproof Enclosure IP67 Mounting Pole/Wall Mounting (Kits included) WIRELESS FEATURES Wireless Standards IEEE 802.11ax/ac/n/g/b/a Frequency 2.4 GHz, 5 GHz Signal Rate • 802.11ax: 8 Mbps to 1201 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80)

• 802.11ac: 6.5 Mbps to 867 Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20/40/80) • 802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40) • 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps • 802.11b: 1, 2, 5.5, 11 Mbps • 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Transmit Power • CE: <20 dBm (2.4 GHz, EIRP), <30 dBm(5 GHz, EIRP) • FCC: <25 dBm (2.4 GHz), <25 dBm(5 GHz) Wireless Functions • 1024-QAM • 4× Longer OFDM Symbol • OFDMA • Multiple SSIDs (Up to 16 SSIDs, 8 for each band) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS (WMM) • MU-MIMO • Omada Mesh • Seamless Roaming • Band Steering • Load Balance • Airtime Fairness • Beamforming • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client Wireless Security • Captive Portal Authentication • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise MANAGEMENT Omada App Yes Centralized Management • Omada Cloud-Based Controller

• Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller

Cloud Access Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) Email Alerts Yes Management MAC Access Control Yes SNMP v1, v2c System Logging Local/Remote Syslog Yes SSH Yes Web-based Management Yes L3 Management Yes Multi-site Management Yes Management VLAN Yes OTHERS Certification CE, FCC, RoHS Package Contents • Access Point EAP610-Outdoor

• Passive PoE Adapter • Power Cord • Mounting Kits • Waterproof Kits • Waterproof Antenna • Installation Guide

Environment • Operating Temperature: -30°C–70°C (-22°F–158°F)

• Storage Temperature: -40°C–70°C (-40°F–158°F) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing schovat popis
