WIRELESS
Standards and Protocols Wi-Fi 7

IEEE 802.11be/ax/ac/n/a 5 GHz
IEEE 802.11be/ax/n/b/g 2.4 GHz

WiFi Speeds BE3600

5 GHz: 2882 Mbps (802.11be)
2.4 GHz: 688 Mbps (802.11be)

WiFi Range Broader Whole Home Coverage

TP-Link Mesh Technology
Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
AI-Driven Mesh
Intelligently learns the network environment to provide ideal Wi-Fi unique to your home
4× High-Performance Antennas (Internal)
Multiple antennas form a signal-boosting array to cover more directions and large areas

WiFi Capacity Very High

Dual-Band
Distribute devices to different bands for optimal performance
OFDMA
Simultaneously communicates with multiple WiFi 7 clients
4 Streams
More than enough bandwidth for connected devices

Working Modes Router Mode

Access Point Mode

Advanced Features • Multi-Link Operation (MLO)

• 160 MHz Channel
• 4K-QAM
• Multi-RUs
• Works with Alexa and Google Assistant

SECURITY
Network Security SPI Firewall

Access Control
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner

Guest Network 1× 5 GHz Guest Network

1× 2.4 GHz Guest Network
Effective Time
Bandwidth Control

VPN Server • OpenVPN Server

• PPTP VPN Server
• L2TP/IPSec VPN Server

VPN Client • OpenVPN Client

• PPTP VPN Client
• L2TP/IPSec VPN Client

WiFi Encryption WPA-Personal

WPA2-Personal
WPA3-Personal

HARDWARE
Ethernet Ports • 2× 1.0 Gbps

*Per Deco Unit
Supports WAN/LAN auto-sensing

Buttons 1× Reset Button

1× WPS

SOFTWARE
Advanced Features • Reboot Schedule

• Tapo/Kasa Onboarding
• IoT network & Device Isolation
• Static Routing Function
• Node/Band Connection Preference

Protocols IPv4

IPv6

Service Kits HomeShield

Learn More>

Parental Controls HomeShield Parental Controls

Youtube Restriction
SafeSearch
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports

WAN Types Dynamic IP

Static IP
PPPoE
PPTP
L2TP

Quality of Service HomeShield QoS

QoS by Device

Cloud Service OTA Firmware Upgrade

TP-Link ID
DDNS

NAT Forwarding Port Forwarding

UPnP

IPTV IGMP Proxy

IGMP Snooping
Bridge
Tag VLAN

DHCP Address Reservation

DHCP Client List
Server

DDNS TP-Link
Management Features Deco App
OTHER
Network Services Enabled by Default Web Server

Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP
DNS
DNS
• Port: 53 Protocol: TCP & UDP
DHCP Server
IP address assignment (DHCP)
• Port: 67 Protocol: UDP
App management
Manage and configure device through app
• Port: 22 Protocol: TCP
• Port: 20001 Protocol: TCP
• Port: 30001 Protocol: TCP
• Port: 20002 Protocol: UDP

PHYSICAL
Dimensions (W×D×H) 5.91 × 5.91 × 2.44 in (150 × 150 × 62 mm)
Package Content

2 Deco BE22 unit
1 RJ45 Ethernet cable
2 Power adapter
Quick Installation Guide

OTHERS
Certifications CE, FCC, RoHS
Environment Operating Temperature: 0°C~40°C (32 °F~104 °F)

Storage Temperature: -40°C~60°C (-40 °F~140 °F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH schovat popis
