Hardware Specifications

CPU
Dual-core, 1.00GHz, Cortex A53
RAM / FLASH
1GB / 256MB
10/100/1000 Mbps RJ-45 ports
1 x WAN: 1 GbE RJ45 port
4 x LAN: 1 GbE RJ45 ports
System Capacity & Performance

SPI firewall throughput LAN to WAN (Mbps)
890
Throughput with threat Management on (Mbps)
880
Wireless Specifications

Standard compliance
IEEE 802.11ax 6 GHz
IEEE 802.11 ax /ac/n/a 5 GHz
IEEE 802.11 ax /n/b/g 2.4 GHz
Wireless frequency
2.4 / 5 /6 GHz
Radio
3
SSID number
4
No. of antenna
4(internal)
Antenna gain
2.0 dBi @ 2.4 GHz
3.0 dBi @ 5 GHz
3.5 dBi @ 6 GHz*
Wireless speed
6 GHz: 2402 Mbps
5 GHz: 2402 Mbps
2.4 GHz: 574 Mbps
Key Features

Security Features
Ransomware / malware protection
Yes
Intrusion blocker
Yes
Dark Web Blocker
Yes
Stop mail fraud & phishing
Yes
Block Ads
Yes
Block VPN proxy
Yes
Web Filtering
Yes
Firewall
Yes
Country Restriction (GeoIP)
Yes
Allowlist / Blocklist
Yes
Traffic Management (applications & clients)
Yes
Real-time threat intelligence1
Yes
Web Filtering (DNS)1
Yes
Nebula Pro Pack*1
Yes
VPN Features
Site-to-site VPN
IPSec
Networking
WAN type
Static IP, DHCP, PPPoE, and PPPoE with Static IP
Networking Features
Port forwarding
Guest VLAN
DHCP
IP/MAC binding
MAC filter
Network Address Translation (NAT) & port forwarding
Yes
DHCP server / client and DHCP relay
Yes
Dynamic DNS
Yes
Network Address Translation (NAT) & port forwarding
Yes
Static route
Yes
IGMP Proxy
Yes
WLAN Management
Firmware upgrade
Yes
Configuration backup and restore
Yes
Live tools
Yes
Power Requirements

Power input
12V DC, 2.0 A
Max. power consumption (Watt Max.)
21W
Physical Specifications

Item
Dimensions (WxDxH)(mm/in.)
178.0 X 54.6 (stand 68.2) X 242.2 mm
Weight (g/lb.)
651g (with stand)
Environmental Specifications

Operating
Temperature
0oC to 40oC
Humidity
10% to 90% (non-condensing)
Storage
Temperature
-30oC to 70oC
Humidity
10% to 95% (non-Condensing)
Certifications
CE
FCC
BSMI
