1. Support for 10th Generation Intel Core™ i9 processors/Intel Core™ i7 processors/Intel Core™ i5 processors/Intel Core™ i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1200 package


2. L3 cache varies with CPU

1. Intel H410 Express Chipset

1. Intel Core™ i9/i7 processors:
   Support for DDR4 2933/2666/2400/2133 MHz memory modules


2. Intel Core™ i5/i3/Pentium/Celeron processors:
   Support for DDR4 2666/2400/2133 MHz memory modules


3. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory


4. Dual channel memory architecture


5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)


6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules


7. Support for Extreme Memory Profile (XMP) memory modules

Integrated Graphics Processor-Intel HD Graphics support:

1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz

Maximum shared memory of 512 MB

1. Realtek ALC887 codec


2. High Definition Audio


3. 2/4/5.1/7.1-channel
   To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.

1. Realtek GbE LAN chip (1000/100 Mbit)

1. 1 x PCI Express x16 slot, running at x16


2. 2 x PCI Express x1 slots
   (The PCI Express slots conform to PCI Express 3.0 standard.)

Chipset:

1. 4 x SATA 6Gb/s connectors

Chipset:

1. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)


2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

1. 1 x 24-pin ATX main power connector


2. 1 x 8-pin ATX 12V power connector


3. 4 x SATA 6Gb/s connectors


4. 1 x CPU fan header


5. 1 x system fan header


6. 1 x RGB LED strip header


7. 1 x front panel header


8. 1 x front panel audio header


9. 1 x USB 3.2 Gen 1 header


10. 1 x USB 2.0/1.1 header


11. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)


12. 1 x serial port header


13. 1 x Clear CMOS jumper

1. 1 x PS/2 keyboard port


2. 1 x PS/2 mouse port


3. 1 x D-Sub port


4. 2 x USB 3.2 Gen 1 ports


5. 4 x USB 2.0/1.1 ports


6. 1 x RJ-45 port


7. 3 x audio jacks

1. iTE I/O Controller Chip

1. Voltage detection


2. Temperature detection


3. Fan speed detection


4. Overheating warning


5. Fan fail warning


6. Fan speed control
   Whether the fan speed control function is supported will depend on the cooler you install.

1. 1 x 128 Mbit flash


2. Use of licensed AMI UEFI BIOS


3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

1. Support for APP Center
   * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
   @BIOS
   Ambient LED
   EasyTune
   Fast Boot
   Game Boost
   ON/OFF Charge
   Smart Backup
   System Information Viewer


2. Support for Q-Flash


3. Support for Xpress Install

1. Norton Internet Security (OEM version)


2. Realtek 8118 Gaming LAN Bandwidth Control Utility

1. Support for Windows 10 64-bit

1. Micro ATX Form Factor; 22.6cm x 17.4cm
