AM4 Socket:

1. AMD Ryzen™ 2nd Generation processors


2. AMD Ryzen™ with Radeon™ Vega Graphics processors


3. AMD Athlon™ with Radeon™ Vega Graphics processors


4. AMD Ryzen™ 1st Generation processors

1. AMD B450

1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory


2. Dual channel memory architecture


3. Support for DDR4 2933/2667/2400/2133 MHz memory modules


4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)


5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules


6. Support for Extreme Memory Profile (XMP) memory modules

(Please refer "Memory Support List" for more information.)

1. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
   * The DVI-D port does not support D-Sub connection by adapter.


2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
   * Support for HDMI 2.0 version and HDCP 2.2.
   Actual support may vary by CPU.

Maximum shared memory of 16 GB

1. Realtek ALC892 codec


2. High Definition Audio


3. 2/4/5.1/7.1-channel


4. Support for S/PDIF Out

1. Realtek GbE LAN chip (10/100/1000 Mbit)

1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
   * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
   Actual support may vary by CPU.
   (The PCIEX16 slot conforms to PCI Express 3.0 standard.)


2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
   The PCIEX4 slot shares bandwidth with the PCIEX1_2 slot. The PCIEX4 slot operates at up to x2 mode when the PCIEX1_2 slot is populated. The PCIEX4 slot operates at up to x4 mode when the PCIEX1_2 is empty.


3. 2 x PCI Express x1 slots
   (The PCIEX4 and PCIEX1 slots conform to PCI Express 2.0 standard.)

1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe 3.0 x4/x2 SSD support)


2. 6 x SATA 6Gb/s connectors


3. Support for RAID 0, RAID 1, and RAID 10
   Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

1. Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies

1. 2 x USB 3.1 Gen 1 ports available through the internal USB header


2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

Integrated in the APU:

1. 4 x USB 3.1 Gen 1 ports on the back panel

1. 1 x 24-pin ATX main power connector


2. 1 x 8-pin ATX 12V power connector


3. 1 x M.2 Socket 3 connector


4. 6 x SATA 6Gb/s connectors


5. 1 x CPU fan header


6. 3 x system fan headers


7. 1 x CPU cooler LED strip/RGB LED strip header


8. 1 x RGB LED strip header


9. 2 x addressable LED strip headers


10. 1 x front panel header


11. 1 x front panel audio header


12. 1 x S/PDIF Out header


13. 1 x USB 3.1 Gen 1 header


14. 1 x USB 2.0/1.1 header


15. 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only)


16. 1 x serial port header


17. 1 x Clear CMOS jumper

1. 1 x PS/2 keyboard/mouse port


2. 1 x DVI-D port


3. 1 x HDMI port


4. 4 x USB 3.1 Gen 1 ports


5. 4 x USB 2.0/1.1 ports


6. 1 x RJ-45 port


7. 6 x audio jacks

1. iTE I/O Controller Chip

1. Voltage detection


2. Temperature detection


3. Fan speed detection


4. Overheating warning


5. Fan fail warning


6. Fan speed control

1. 1 x 128 Mbit flash


2. Use of licensed AMI UEFI BIOS


3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

1. Support for APP Center
   Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
   3D OSD
   @BIOS
   AutoGreen
   Cloud Station
   EasyTune
   Fast Boot
   Game Boost
   ON/OFF Charge
   RGB Fusion
   Smart Backup
   Smart Keyboard
   Smart TimeLock
   Smart HUD
   Smart Survey
   System Information Viewer
   USB Blocker


2. Support for Q-Flash


3. Support for Xpress Install

1. Norton Internet Security (OEM version)


2. Realtek 8118 Gaming LAN bandwidth Control Utility

1. Support for Windows 10 64-bit


2. Support for Windows 7 64-bit
   To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
   Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.

1. ATX Form Factor; 30.5cm x 23.5cm

1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.


2. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
