1. Support for 9th and 8th Generation Intel Core™ i9 processors/Intel Core™ i7 processors/Intel Core™ i5 processors/Intel Core™ i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package


2. L3 cache varies with CPU

   (Please refer "CPU Support List" for more information.)

1. Intel B365 Express Chipset

1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory


2. Dual channel memory architecture


3. Support for DDR4 2666/2400/2133 MHz memory modules


4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)


5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules


6. Support for Extreme Memory Profile (XMP) memory modules
   To support 2666 MHz or XMP memory, you must install a 9th or 8th Generation Intel Core™ i9/i7/i5 processor.

   (Please refer "Memory Support List" for more information.)

Integrated Graphics Processor-Intel HD Graphics support:

1. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
   The DVI-D port does not support D-Sub connection by adapter.


2. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
   Support for DisplayPort 1.2 version, HDCP 2.2, and HDR.


3. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
   Support for HDMI 1.4 version and HDCP 2.2.

Support for up to 3 displays at the same time
Maximum shared memory of 1 GB

1. Realtek ALC892 codec


2. High Definition Audio


3. 2/4/5.1/7.1-channel


4. Support for S/PDIF Out

1. Intel GbE LAN chip (10/100/1000 Mbit)

1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
   For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.


2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)


3. 1 x PCI Express x1 slot
   (All of the PCI Express slots conform to PCI Express 3.0 standard.)


4. 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)

1. Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies

Chipset:

1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2Q)


2. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2A)


3. 6 x SATA 6Gb/s connectors


4. Support for RAID 0, RAID 1, RAID 5, and RAID 10
   Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

Intel Optane™ Memory Ready

Chipset:

1. 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 1 support


2. 5 x USB 3.1 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)


3. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

1. 1 x 24-pin ATX main power connector


2. 1 x 8-pin ATX 12V power connector


3. 1 x CPU fan header


4. 3 x system fan headers


5. 2 x addressable LED strip headers


6. 2 x addressable LED strip power select jumpers


7. 2 x RGB LED strip headers


8. 6 x SATA 6Gb/s connectors


9. 2 x M.2 Socket 3 connectors


10. 1 x front panel header


11. 1 x front panel audio header


12. 1 x S/PDIF Out header


13. 1 x USB 3.1 Gen 1 header


14. 2 x USB 2.0/1.1 headers


15. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)


16. 1 x serial port header


17. 1 x Clear CMOS jumper

1. 1 x PS/2 keyboard/mouse port


2. 1 x DVI-D port


3. 1 x DisplayPort


4. 1 x HDMI port


5. 1 x USB Type-C™ port, with USB 3.1 Gen 1 support


6. 3 x USB 3.1 Gen 1 ports


7. 2 x USB 2.0/1.1 ports


8. 1 x RJ-45 port


9. 6 x audio jacks

1. iTE I/O Controller Chip

1. Voltage detection


2. Temperature detection


3. Fan speed detection


4. Overheating warning


5. Fan fail warning


6. Fan speed control
   Whether the fan speed control function is supported will depend on the cooler you install.

1. 2 x 128 Mbit flash


2. Use of licensed AMI UEFI BIOS


3. Support for DualBIOS™


4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

1. Support for APP Center
   Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
   3D OSD
   @BIOS
   AutoGreen
   Cloud Station
   EasyTune
   Easy RAID
   Fast Boot
   Game Boost
   ON/OFF Charge
   Platform Power Management
   RGB Fusion
   Smart Backup
   Smart Keyboard
   Smart TimeLock
   Smart HUD
   Smart Survey
   System Information Viewer
   USB Blocker


2. Support for Q-Flash


3. Support for Xpress Install

1. Norton Internet Security (OEM version)


2. cFosSpeed

1. Support for Windows 10 64-bit

1. Micro ATX Form Factor; 24.4cm x 24.4cm

1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.


2. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
